Product Details:
|
|
| Place of Origin: | China |
|---|---|
| Brand Name: | ZT-PACK |
| Certification: | CE,ISO,SGS,SABER |
| Model Number: | LP-200 |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 1set |
| Price: | Negotiable |
| Packaging Details: | Wooden Case |
| Delivery Time: | 30 days |
| Payment Terms: | TT/LC |
| Supply Ability: | 30 sets per month |
4000BPH plastic bottle unscramble machine for a small bottle
Description
The equipment suits the automatic bottle-feeding of all kinds of cylinder-shaped bottles for the industry, such as daily chemical industry, pesticide, and chemical industry. With its bottle-feeding speed is fast, steady and reliable performance, and convenient operation, it may link with the assembly line.
Parameters:
| Applicable Bottle Diameter | Φ36－95mm |
| Applicable Bottle Height | 80-240mm |
| Speed | 4000BPH |
| Air Pressure | 0.5～0.7 MPa |
| Power | 2 KW |
| Power Source | AC220V, 50Hz |
| Bottle-Elevator Dimension | 2200×1000×1900(L×W×H) mm |
| Unscramble Dimension | 2600×1450×1370(L×W×H) mm |
| Weight | 1250Kg |
Configure:
| No. | Name | Brand |
| 1 | Frequency converter | Schneider |
| 2 | Magnetic Switch | Schneider |
| 3 | Sensor | OPTEX |
| 4 | Power Switch | Schneider |
| 5 | Cylinder | AIRTAC |
Suitable For Filling: Applicable to all plastic bottles, not limited to square or round bottles, widely used in daily chemicals, oils, pesticides, and personal care.
Feature:
1, Simple structure , easy operation and convenient adjustment . Compact structure, small floor space, simple whole machine, only three operation buttons, simple operation, one key finish to make. Good versatility, can share for :50-1000ml bottles.
2, When changing different size bottle, there is no need to change model.Its applicable range is 50-1000ml bottles. You only need to adjust belt in the bottle hopper and the space of the unscrambling structure.
3, It adopted the US technology. Good stability and its qualified rate is 100%.
4, The whole machine is covered with organic glasses, you can open all the cover for easy adjustment.
5, The electrical components are all imported which ensures its long service time, stability and reliability.
6, The connecting belt in the machine are shaped in one time, not easy to broken.
7, Automatic bottle elevating function, you only need to put the bottles in the bottle elevator, a sensor is installed in the rotary plate, it will automatically elevate the bottles when there is not enough bottle,and it will start when the bottles are enough consequently.
