Product Details:
|
|
| Place of Origin: | China |
|---|---|
| Brand Name: | ZT-PACK |
| Certification: | CE,ISO,SGS,SABER |
| Model Number: | ZSP |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 1 set |
| Price: | Negotiable |
| Packaging Details: | Wooden Case |
| Delivery Time: | 30days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 45sets per month |
Containers and Specifications (50mL-1000mL)
|
Containers and Specifications(100mL-1000mL)
|
|||||
| Model | ZSP-6A | ZSP-8A | ZSP-10A | ZSP-12A | ZSP-16A |
| Dimension | 2200mm(L)x1100mm(W)x2200mm(H) | 2300mm(L)x1100mm(W)x2200mm(H) | 2400mm(L)x1100mm(W)x2200mm(H) | ||
| Filling head | 6 | 8 | 10 | 12 | 16 |
| Capacity(1L) | 1800B/H | 2400B/H | 3000B/H | 3600B/H | 4800B/H |
| Power | 2.2KW | 2.2KW | 2.2KW | 3KW | 3KW |
| Suitable bottle | Diameter:Φ40mm-Φ100mm Height:80mm-280mm | ||||
| Neck diameter | Φ18mm | ||||
| Filling range | 50ml--1000ml(From ZT-PACK) | ||||
| Air pressure |
0.6Mpa--0.8Mpa
|
||||
| Power supply | 380V;50HZ/60HZ | ||||
