Product Details:
|
|
| Place of Origin: | China |
|---|---|
| Brand Name: | ZT-PACK |
| Certification: | CE,ISO,SGS,SABER |
| Model Number: | ZCJ |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 1set |
| Price: | Negotiable |
| Packaging Details: | Wooden Case |
| Delivery Time: | 30 days |
| Payment Terms: | TT/LC |
| Supply Ability: | 45 sets per month |
5-20 Liter Liquid Drum Linear Weight System Liquid Fill Machine 20 Liters Liquid Filling Machine
Product Application
The machine has controlled by PLC, it can feed bottles, count bottles and peel weighting automatically. This product manufactured with a high degree of automation, every filling head has one high-precision weighing feedback system and it could set volume for each head or fine turning for single head to ensure same volume. Whole machine made of stainless steel, with diving filling(fast and slow) function, also could effectively reduce foam
Main performance parameter:
1 Filling range:5-30kg
2 Bottle size range : L: 160mm~360mm
W: 140mm~260mm
H: 250mm~500mm
(Min: 140 × 200 × 320 mm , Max: 260 × 290 × 500 mm)
3 Diameter of bottle mouth:≥Φ40mm
4 Power Supply: ~ 220 V, 50 Hz
5 the total power: 3.5 kW
6. Air consumption:120L/Min
7 measurement accuracy: ± 0.5% (Note: Filling accuracy depends on the viscosity of the material as well as the continuity and stability of the material supply);
8 Production capacity:≤480bottles/hour
9 Bottle feed direction:From left to righ
|
1. Capacity
|
600(b/h)
|
|
2. filling volume
|
10-25L
|
|
3. measurement precision
|
±35ml
|
|
4. applicable bottle diameter
|
L≤350mm,W≤280mm
|
|
5. applicable bottle height
|
≤450mm
|
|
6. air pressure
|
0.6-0.8Mpa
|
|
7. total power
|
2Kw
|
|
8. voltage
|
AC220V,50/60Hz
|
|
9. net weight
|
950kg
|
|
10. dimension
|
2400(L)×1600(W)×2300(H)mm
|
Feature:
1.Heavy duty stainless steel construction
2.High speed & volume production
3. High accuracy fill, less product waste
4. Automatic bottling index kit with bottle counter
5. Individual fill head control Durable construction to ensure longer life of the machine
6. Real time net weight monitor
7. Drip pan
8. User friendly PLC controls with touch screen HMI Easy change over to different size bottles.
9. Low maintenance & operating cost
10. Designed with common parts for easy & quick replacement
11. Adaptable to fit a variety of different container styles & sizes
12. No bottle, No filling
Suitable For Filling: Big volume edible oil / Wine / Lubrication / Liquid Fertilizer / Chemicals ...Etc kinds Products
