Product Details:
|
|
| Place of Origin: | China |
|---|---|
| Brand Name: | ZT-PACK |
| Certification: | CE,ISO,SGS,SABER |
| Model Number: | ZSP-A |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 1 set |
| Price: | Negotiable |
| Packaging Details: | Wooden Case |
| Delivery Time: | 30days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 100 sets per month |
Suitable for fill: Lubricant Oil / Car Oil / Motor Oil / coolant liquid / engine oil / Lubricanting Oil kinds Products
Filling Range:
50ml -1000ml
1L -5L
4L -20L
208L / 220L
Speed can be choosen : from 1000BPH-6000BPH (basic on 1L ) contact us for more details
Parameters:
| Model | ZSP-6A | ZSP-8A | ZSP-10A | ZSP-12A | ZSP-16A |
| Dimension | 2200×1100×2200mm (L×W×H) | 2300×1100×2200mm (L×W×H) | 2400×1100×2200mm (L×W×H) | ||
| Filling head | 6 | 8 | 10 | 12 | 16 |
| Capacity(1L) | 1800B/H | 2400 B/H | 3000 B/H | 3600 B/H | 4800 B/H |
| Power | 2.2KW | 2.2 KW | 2.2KW | 3KW | 3KW |
| Suitable bottle | Diameter:Φ40mm——Φ100mm Height:80mm——280mm | ||||
| Neck diameter | Φ18mm | ||||
| Filling range | 50ml——1000ml /1L-5L (From ZT-PACK) | ||||
| Air pressure | 0.6Mpa-0.8Mpa | ||||
| Power supply | 380V ；50HZ / 60HZ | ||||
Details:
