Product Details:
|
|
| Place of Origin: | CHINA |
|---|---|
| Brand Name: | ZT-PACK |
| Certification: | CE/ SGS/ ISO |
| Model Number: | TSB-150 |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 1set |
| Price: | negotiable |
| Packaging Details: | wooden packages |
| Delivery Time: | 15 days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 45sets/month |
Shrink Sleeve Labeling Machine With Electric Tunnel
Equipments general introduction:
This machine massively has used the aluminum alloy and high strength, the anti-corrosive stainless steel, causes the machine over all overhead construction firmer durable, in the machine performance the modulation, the human nature design causes each adjustment easier, the replacement model is simpler. Using the man-machine contact surface in the control system to control, which is easy to study and understand.
Uses:
TSB-150 machine is with high automatization, strong corrosion resisting, simple to operate and convenient to maintain. Wrap label widely used in each kind of bottled product, like the drinks, the healthy product, the cosmetics, wash product, the medicine (agriculture)leechdom, petroleum etc. the product.
| 1 | Machine model | TSB-150 |
| 2 | Main machine size | 2440×1000×2100 (mm) |
| 3 | Equipment size | 4500×1050×2200 (mm) |
| 4 | Equipment weight | 550Kg |
| 5 | Capacity | 6000BPH |
| 6 | Suitable bottle (mouth) diameter | Φ50~Φ90mm |
| 7 | Wrap label length | 40 ~180 mm |
| 8 | Label thickness | 0.035 ~ 0.10mm |
| 9 | Volume label material | PVC, PET,OPP, OPS |
| 10 | Volume label shrinker | Electric type |
| 11 | Operation mode | Entirely automatic control |
Suitable for working :
Working principal :
Machines Details Pictures :
